Features:

• Suitable for use on timber doors hinged on the left or right and requires key & lever handle operation.
• To suit doors up to 54mm thick.
• Deadbolt locked or unlocked by key from either side.
• Latch bolt withdrawn by lever handle from either side.
• Extended 20mm deadbolt for secure positive deadlocking and additional resistance against attack.
• 2234E may be keyed alike with 2134E.
• Pierced to accept bolt through furniture.
• Reversible latch bolt from outside of case.
• Anti-pick and anti-saw security Features:
• Available with square forend and striking plate.
• The 2234E series locks are recommended by insurance companies, kite marked to BS3621 - 2007 (British Standard) and has been approved by the police Secured by Design initiative.
• They are also covered by a 15 Year guarantee.

Technical data:

• Case Size - 67x111mm (2½")
• Backset - 45mm
• Case - Steel, red powder coat
• Forend - Satin chrome
• Striking Plate - Security box type, finished to match forend
• Deadbolt - Brass, with hardened steel rollers
• Latch Bolt - Brass, reversible
• Follower - Brass, 8mm square
• Rebate Kit - 2964 (13mm, 19mm or 25mm)
• Key Blank Number - KB430

Supplied with:

• 3 x Steel nickel plated keys

Please note - Not suitable for master keying.
