Features:

• An ideal solution for meeting the gas safety industry’s and Building Regulations Part J’s concealed boiler blue inspection access requirements (non-fire related applications).
• Cost effective product.
• Saves time and money compared with site-made or steel access doors.
• Smart aesthetic appearance and finish.
• Lightly textured finish allows painting if required.
• Picture frame surround smartly conceals cut out edges.
• Picture frame surround contributes to a faster installation.
• Universal door handing.
• Flush fitting door panel can be fully removed for maximum access.
• Installed in minutes using basic hand tools and silicone/flexible sealant.
• Catch clip secure closing mechanism.

Technical data:

• Acoustic Performance - 26dB
• Overall panel frame - 510x510mm
• Clear opening size - 455x455mm
• Frame fitting size - 470x470mm
• Visible frame width - 25mm
• Depth - 12mm
• Material - Tough and UV stabilised injection moulded HIPS/ABS plastic
• Colour - White (Can be painted if required)
• Manufactured to - BS EN ISO 9001 Quality Management System
• Manufactured to - BS EN ISO 14001 Environmental Management System
• Building Regulation - Document Part J Concealed Flues in Voids (2010 edition)
• Brand - Timloc

Applications:

• Dry lined walls.
• Ceilings.
• Ducts Cupboards/Units.
