A 2000 year old profile with precision-engineered functionality

Features:

• A classic profile for meeting planning requirements.
• Suitable for use with universal tile vents.
• With minimum pitch of 22.5°.
• Flexible easy to lay open gauge.
• High coverage - 10.1 tiles per m² at maximum gauge.

Technical data:

• Brand - Marley
• Product Type - Double Roman Roof Tile
• Material - Concrete
• Colour - Grey
• Finish - Smooth
• Depth - 53mm
• Width - 330mm
• Length - 420mm
• Weight Of Tiling (Approx.) - 44kg/m2 (0.43 kN/m2) at 75mm Headlap / 47kg/m2 (0.46 kN/m2) At 100mm Headlap
• Min. Pitch (Smooth) - 25° (75mm Headlap) / 22.5° (100mm Headlap)
• Covering Capacity - 9.7 Tiles/m² (75mm Headlap)
• Tile Nails - 65mm x 3.35mm
• Fixing Clips- Eaves, Verge And Tile Clips

Standards & Certifications:

• A+ rated in the BRE Green Guide (based on generic rating for UK produced concrete interlocking tiles
• BES 6001 Responsible Sourcing certified
• BS EN 490
