Marley Acme Clay Single Camber Plain Roof Tile Smooth Mixed Brindle

In stock
Product Code
109138655
The Acme Single Camber clay plain tile allows the creation of traditional and contemporary low pitch roof designs with the warmth and character of clay. Features: Precision...Read more
Your Price
£0.95 £0.79

Add to Project List

The Acme Single Camber clay plain tile allows the creation of traditional and contemporary low pitch roof designs with the warmth and character of clay.

Features:

  • Precision manufacturing at its finest: all the benefits of a strong, natural material with cutting-edge modern production techniques.
  • Compatibility, functionality and beautiful aesthetics for the perfect finish across every roof style.
  • With first-rate environmental credentials, Acme Single Camber Clay Plain tiles could be the solution for your roofing project.
  • Compatible with Marley roof systems and with Marley SolarTile®.
  • Manufactured in the heart of Staffordshire, clay plain tiles benefit from using what’s widely considered to be the strongest and most durable natural clay in the market - Staffordshire Etruria Marl.

Technical data:

  • Brand - Marley
  • Range - Acme
  • Product Type - Single Camber Plain Roof Tile
  • Material - Clay
  • Colour - Mixed Brindle
  • Finish - Smooth
  • Width - 165mm
  • Length - 265mm
  • Minimum Pitch - 30Degree
  • Maximum Pitch - 90Degree
  • Minimum Headlap - 65mm (Roof) / 35mm (Vertical)
  • Maximum Gauge 100mm (Roof) / 115mm (Vertical)
  • Cover Width - 165mm (Nominal)
  • Tile Thickness - 11mm (Nominal)
  • Covering Capacity (Net) - 60 Tiles/m² At 100mm Gauge (Roof) / 53 Tiles/mm² At 115mm Gauge (Vertical)
  • Weight of Tiling - 64kg/m² (0.63 kN/m²) At 100mm Gauge (Roof) / 56kg/m² (0.55 kN/m²) At 115mm Gauge (Vertical)
  • Battens Required (Net) - 10.0 lin.m/m² At 100mm gauge (Roof) / 8.7 lin.m/m² At 115mm Gauge (Vertical)
  • Batten Size Recommended - 38mm x 25mm for Rafters / Supports not exceeding 600mm centres (fixed to BS 5534)
  • Tile Nails - 38mm x 2.65mm

Standards & Certifications:

  • Accreditation to the BES 6001 Framework Standard for Responsible Sourcing means that projects using our clay tiles can get extra credits under BREEAM.
  • Authority BS EN 1304
  • Green guide rating A+ (Element ref: 812410006)

Please Note:

  • The minimum recommended pitch and lap may be influenced by special circumstances, please contact the Technical Advisory Service.

  • Manufacturer Code
    MAKE309AB
  • Product Type
    Single Camber Plain Roof Tile
  • Finish
    Smooth
  • Width
    165mm
  • Length
    265mm
  • Range
    Acme
  • Material
    Clay
  • Colour
    Mixed Brindle
  • Brand
    Marley
  • Brand
    Marley
