Knightsbridge Curved Edge Cooker Connection Unit 45Amp White

Knightsbridge Curved Edge Cooker Connection Unit 45Amp White

Name: Knightsbridge Curved Edge Cooker Connection Unit 45Amp White
Brand: Knightsbridge
SKU: 109133873
Price: 5.24 GBP
Availability: InStock

Knightsbridge Curved Edge Cooker Connection Unit 45Amp White

In stock

Product Code

109133873

A cooker connection unit contains both the cooker switch and a cooker socket, which can act as an isolator. Your appliance needs to be connected via a thick cable to the so-called cooker connect...Read more

DISCLAIMER

This product qualifies for next working day delivery provided it is in stock and your order is placed by 1pm Monday to Thursday. For full T&C's read our Delivery Information.

Your Price

£5.24 £4.37

Select branch to check stock

Select postcode to see availability

Product Information

Features:

Gently contoured 23mm plate with rounded edges and anti-microbial properties.
45Amp rated.
Concealed fitting, large capacity easy to wire terminals.
Clamp fitted with a bottom knockout for outgoing cable.

Technical data:

Brand - Knightsbridge
Range - Curved Edge
Product Type - Cooker Connection Unit
Material - Thermoset Resin
Colour - White
Projection - 23mm
Height - 86mm
Width - 86mm
Weight - 71g
Min. Mounting Box Depth - 25mm
IP Rating - IP20
Voltage - 230V / 50Hz
Amperage - 45Amp

Standards & Certifications:

Certified to BS 5733

Supplied with:

Fixing screws and screw cap covers.
Knightsbridge rip top polybag with euro slot.

Manufacturer Code
CU8340
Delivery Only
No
Brand
Knightsbridge
Range
Curved Edge
Product Type
Cooker Connection Unit
Material
Thermoset Resin
Colour
White
Width
86mm
Height
86mm
Projection
23mm
Weight
71g
Voltage
230V

Shipping and Returns

Check for Delivery

Returns

This product can be returned if returned unopened, unused and in a fully resalable condition, including the original packaging.

Click here for the MP Moran return policy

Datasheets

Knightsbridge Curved Edge Cooker Connection Unit 45Amp White Data Sheet
