Europa MCB 1 Pole B Curve 20Amp 6kA

Name: Europa MCB 1 Pole B Curve 20Amp 6kA
Brand: Europa
SKU: 109136006
Price: 1.49 GBP
Availability: InStock

Europa MCB 1 Pole B Curve 20Amp 6kA

In stock

Product Code

109136006

A miniature circuit braker by Europa designed to protect an electrical circuit from damage caused by an overcurrent or short circuit. Features: Its basic function is to int...Read more

DISCLAIMER

This product qualifies for next working day delivery provided it is in stock and your order is placed by 1pm Monday to Thursday. For full T&C's read our Delivery Information.

Last chance to buy!

Great products, at even better prices...

But hurry as once they are gone, they are gone!

Your Price

£1.49 £1.24

Out of stock

Product Information

A miniature circuit braker by Europa designed to protect an electrical circuit from damage caused by an overcurrent or short circuit.

Features:

Its basic function is to interrupt current flow to protect equipment and to prevent the risk of fire.
Cable & fault protection for added safety.
Flexible install options.
Range uniformity.
Easily identify the fault.
Simple to resume supply.
More sensitive than fuses.
Less maintenance and replacement cost.

Technical data:

Brand - Europa
Product Type - Miniature Circuit Braker MCB
Curve - B
No. of Poles - 1
Amperage - 20Amp
Voltage - AC 230(240)
Rated Frequency - 50/60Hz
Rated Impulse Withstand Voltage (Uimp) - 4kV
Operating Temperature - -5° to 40°C
Rated Short Circuit Capacity (Icn) - 6kA
Altitude- < 2000mtr
Humidity - < 50% at 40°C and 90% at 20°C
IP Rating - IP20
Mounting - 35mm DIN Rail

Standards & Certifications:

Standard(s) IEC 60898, EN 60898
Certification CE, SEMKO

Manufacturer Code
EUB120B
Delivery Only
No
Brand
Europa
Product Type
MCB (Miniature Circuit Breaker) B Curve
IP Rating
IP20
Voltage
AC 230(240)
Amperage
20Amp
