The Thomas Dudley Miniflo concealed cistern is conveniently compact in size and straightforward to fit. It is perfect for use in all domestic and commercial applications and can be used with confidence in fitted bathroom furniture or behind tiles and most partitioning materials.

Features:

• This concealed cistern comes packaged with a complimenting dual flush button and is pre-assembled and ready to install.
• An extensive range of Dudley push buttons, push plates, levers and touch-free electronic sensors are also compatible with this unit.
• Factory assembled for quick and easy installation.
• Top access panel with compact dimensions fit neatly into 150mm ducts.
• Air tubes enable button plate or sensor to be installed up to 750 mm away from the cistern.
• 6 or 4 litres dual flush which converts to 5 or 3 or 4 or 2.6 litres dual flush.
• Cistern body in high density polyethylene with internal overflow warning.

Supplied with:

• One piece cistern fixing brackets.
• Supplied with a WRAS approved Dudley Niagara flushing valve.
• Supplied with a WRAS approved Dudley delay fill Hydroflo quiet inlet valve.
• Supplied with a push-fit flush bend.

Technical data:

• Brand - Dudley
• Range - Miniflo
• Product Type - Compact Concealed Toilet Cistern
• Material - High Density Polystyrene
• Colour - White
• Depth - 131mm
• Height - 276mm
• Width - 411mm
• Flush Volume - 6 To 4ltr
