Domestic wiring cable. Can be installed in fixed installations in dry or damp premises clipped to surface, on trays or in free air where mechanical damage would not be an issue. Suitable for laying in conduit or trunking where mechanical protection is required.

Features:

• A three-core and earth cable, which means that it has three insulated conductors (usually brown, blue, and black) and a bare copper earth wire.
• The "Y" in the cable code indicates that it is a PVC (polyvinyl chloride) insulated cable.

Applications:

• Trunking where mechanical protection is required.
• Suitable for higher load 2-way lighting circuits.

Technical data:

• Range - 6243Y
• Product Type - Cable 3 Core & Earth
• Insulation Material - PVC
• Amperage - 20Amp
• Sheath Colour - Grey
• Sheath Core Colours - Brown / Black / Grey
• No. of Cores - 3+E
• Length - 5mtr
• Core Diameter - 1.5mm²
• Voltage - 300V / 500V
• Operating Temperature - -15°C To 70°C
• Short Circuit Temperature 160°C
• Minimum Bending Radius - 8xD
• Max. Conductor Resistance At 20°C - 18.1Ohm/km
• Type Of Copper Conductor - Solid

Standards & Certifications:

• BASEC Approved
• UKCA CE ISO 9001
• Standard: BS 6004:2012

Please Note:

• Should only be installed by a qualified electrician.
